“Rock Paper Scissors” Documentation by “Code This Lab S.r.l.” v1.0


“Rock Paper Scissors”

Created: 03/05/2017
By: Code This Lab S.r.l.
Email: info@codethislab.com

Thank you for purchasing our game. If you have any questions that are beyond the scope of this help file, please feel free to email via user page contact form here. Thanks so much!


Table of Contents

  1. Description
  2. Folder Contents
  3. Getting Started
  4. HTML Structure
  5. CSS Files and Structure
  6. Source Code
  7. Game functions
  8. Change Graphic
  9. Disable Sounds
  10. Wordpress Plugin

A) Description - top

Rock Paper Scissor is a HTML5 Arcade Game Play against the CPU or challenge a friend. Few simple rules: stone breaks scissor, sheet wraps stone and scissor slices the sheet. Good Luck!

The ZIP package contains the game with 1200x600 resolution that scales to fit the whole screen device
Just warning that for very wide screens, the game may not be perfectly full screen. The game is fully compatible with all most common mobile devices.
Sounds are enabled for mobile but we can't grant full audio compatibility on all mobile devices due to some well-know issue between some mobile-browser and HTML5. So if you want to avoid sound loading, please read Disable Sound section).
WARNING: Sounds can't be enabled for Windows Phone as this kind of device have unsolved issues with 'audio' and 'video' tag.


B) Folder Contents - top

The item package contains the following folders:


C)Getting Started - top

To install the game just upload on your server the game folder live_demo.


D)HTML Structure - top

This game have the canvas tag in the body. The ready event into the body calls the main function of the game: CMain().
The head section declares all the javascript functions of the game. The whole project uses a typical object-oriented approach.
In the init function there are 4 mapped events that can be useful eventually for stats







  • Game option: You can easily customize game setting when creating a new instance of the game in index.html file
  • 					var oMain = new CMain({
    					fullscreen:true, 				//SET THIS TO FALSE IF YOU DON'T WANT TO SHOW FULLSCREEN BUTTON
                        check_orientation: false,    	//SET TO FALSE IF YOU DON'T WANT TO SHOW ORIENTATION ALERT ON MOBILE DEVICES
    					victoryOccurences: 50           //0-100 possibility of the player to win

    					});


    E) CSS Files and Structure - top

    The game use two CSS files. The first one is a generic reset file. Many browser interpret the default behavior of html elements differently. By using a general reset CSS file, we can work round this. Keep in mind, that these values might be overridden somewhere else in the file.

    The second file contains all of the specific stylings for the canvas and some hack to be fully compatible with all most popular mobile devices


    F) Source Code - top

    This game contains:

    1. jQuery
    2. Our custom scripts
    3. CreateJs plugin
    1. jQuery is a Javascript library that greatly reduces the amount of code that you must write.
    2. The game have the following js files:
      • CMain: the main class called by the index file.
        This file controls the sprite_lib.js file that manages the sprite loading, the loop game and initialize the canvas with the CreateJs library
      • ctl_utils: this file manages the canvas resize and its centering
      • sprite_lib: this class loads all images declared in the main class
      • settings: general game settings
      • CLang: global string variables for language localization
      • CPreloader: simple text preloader to show resources loading progress
      • CMenu: simple menu with the play button
      • CGfxButton: this class create a standard button
      • CToggle: this class create a standard toggle button
      • CTextButton: this class create a standard text button
      • CGame: this class manages the game logic
      • CInterface: this class controls game GUI that contains text and buttons
      • CPlayer: this class manages the human player
      • CCpuPlayer: this class controls the CPU Player.
      • CEndPanel: this class is a simple panel that show you score at the end of the game.
      • CHelpPanel: this class is a simple panel that show how to play.
      • CAreYouSurePanel: this class is a simple panle that show you a message to be sure that you want to exit
      • CCreditsPanel: this class is a simple panel that display info about the creator of the game.
      • CGameSection: this class manage the panel where the hands are displayed.
      • CHistoryPanel: this class manage the panel where is displayed the number of round win.
      • CMatchCount: this class is a simple toggle to sign whether or not the round is won.
      • CRecordPanel: this class manage the panel where is displayed the progress of the player.
      • CSelectPlayers: this class manage the panel where the user set how many players are playing.
      • CSelectThrow: this class is a simple panel that let the player choose what will be his next throw.
      • CMatchCount: this class is a simple toggle to sign whether or not the round is won.
    3. CreateJs is a suite of modular libraries and tools which work together to enable rich interactive content on open web technologies via HTML5.

    Resuming, the complete game flow is the following:

    1. The index.html file calls the CMain.js file after ready event is called
    2. The main class calls CPreloader.js to init preloader text and start sprite loading
    3. When all sprites contained in "/sprites" and "/sounds" folder are loaded, the main class removes the preloader and calls the CMenu.js file that shows the main menu
    4. If the user click the Play button in main menu, the CGame.js class is called and game starts
    5. CGame.js creates than the stage, and show the user the panel to choose how many players are playing and call the main game loop using the Update() function
    6. In the main game loop are handled the graphics to show and animate, and if there is only one player decides the CPU Throw
    7. If the user click on the exit button in the down-right corner, the game returns to the menu screen

    G) Game functions - top

    In this section will be explained all the most important functions used in CGame.js file.


    H) Change Graphic - top

    You can easily change all the game graphic, replacing all the file you need in the "/sprites" folder. Just respect file format (.png or .jpg) and size if you don't want to change any code line.

    I) Disable Sounds - top

    If you want to disable all the sounds for mobile devices, you have to change the following value in settings.js file:

    var DISABLE_SOUND_MOBILE = true;


    J) Wordpress Plugin - top

    CTL Arcade will allow you to add a real arcade on your worpress website, in this way your users will be more involved and will stay connected longer.

    It's possible to add Ads banner at the beginning of each game and at the end of each level. This will give you a new tool to increase your revenues.

    Your own users will promote your website sharing their scores on the main Social Networks, with no extra costs for you.

    You'll get by default the score-sharing on Twitter. To add Facebook just follow the guideline below.

    3 widgets can be added in your pages through a shortcode.

    Minimum Requirements:

    This plugin is designed to work only with games built by Code This Lab.

    You can find it here!

    ctl arcade

    Once again, thank you so much for purchasing this game. Feel free to contact us if you have any questions or issue relating to this game. No guarantees, but we'll do our best to assist.

    CODE THIS LAB S.R.L.

    Go To Table of Contents
