“Spin and Win” Documentation by “Code This Lab S.r.l.” v1.0


“Spin and Win”

Created: 07/07/2017
By: Code This Lab S.r.l.
Email: info@codethislab.com

Thank you for purchasing our game. If you have any questions that are beyond the scope of this help file, please feel free to email via user page contact form here. Thanks so much!


Table of Contents

  1. Description
  2. Folder Contents
  3. Getting Started
  4. HTML Structure
  5. CSS Files and Structure
  6. Source Code
  7. Game functions
  8. Change Graphic
  9. Disable Sounds
  10. Wheel Customization
  11. Wordpress Plugin

A) Description - top

Spin and Win is a HTML5 Instant Win Game. Spin the Wheel and win the prize you've ever dreamed of!

The ZIP package contains the game with 768x1280 resolution that scales to fit the whole screen device
Just warning that for very wide screens, the game may not be perfectly full screen. The game is fully compatible with all most common mobile devices.
Sounds are enabled for mobile but we can't grant full audio compatibility on all mobile devices due to some well-know issue between some mobile-browser and HTML5. So if you want to avoid sound loading, please read Disable Sound section).
WARNING: Sounds can't be enabled for Windows Phone as this kind of device have unsolved issues with 'audio' and 'video' tag.


B) Folder Contents - top

The item package contains the following folders:


C)Getting Started - top

To install the game just upload on your server the game folder live_demo.


D)HTML Structure - top

This game have the canvas tag in the body. The ready event into the body calls the main function of the game: CMain().
The head section declares all the javascript functions of the game. The whole project uses a typical object-oriented approach.
In the init function there are 5 mapped events that can be useful eventually for stats







  • Game option: You can easily customize game setting when creating a new instance of the game in index.html file
  •                                     var oMain = new CMain({
                                            wheel_spin_time: 14,    //TIME (in seconds) OF A SPIN

                                                //INSTANT_WIN_WHEEL_SETTINGS sets the win occurrence of each prize in the wheel.
                                                //      -background: THE BACKGROUND IMAGE NAME IN sprites/item_prize_images FOLDER (the images name MUST ALWAYS BE image_#)
                                                //      -win_occurrence: THE WIN OCCURRENCE OF THAT PRIZE. THE RATIO IS CALCULATED WITH THE FORMULA: (single win occurrence/sum of all occurrences). For instance, the prize associated to image_0, have occurrence 7/70 because the sum of all slices occurrences is 70.
                                                //      -prizewinning: STATES WHETHER THE PRIZE IS WINNING OR NOT.
                                                //              IF "false", THE PRIZE HAS NO VALUE AND WILL BE CONSIDERED AS A LOSE. THE GAME WILL CONTINUES UNTIL THE NUM. SPINS ENDS OR PLAYER WINS.
                                                //              IF "true", THE PRIZE IS CONSIDERED AS A WIN, THE GAME ENDS AND THE PLAYER WILL BE REDIRECTED TO A REDEEM LINK
                                                //      -label: INSERT A DESCRIPTION OF THE OBJECT. IF YOU DON'T WANT TO ADD ANY LABEL, LEAVE THE FIELD AS IT IS: (label: "") LABEL WON'T BE SHOWN, IS JUST A REMINDER.
                                                instant_win_wheel_settings: [
                                                    {background: "image_0", win_occurrence:7, prizewinning: true, label: ""},
                                                    {background: "image_1", win_occurrence:7, prizewinning: true, label: ""},
                                                    {background: "image_2", win_occurrence:7, prizewinning: false, label: ""},
                                                    {background: "image_3", win_occurrence:7, prizewinning: true, label: "romantic dinner"},
                                                    {background: "image_4", win_occurrence:7, prizewinning: true, label: ""},
                                                    {background: "image_2", win_occurrence:7, prizewinning: false, label: ""},
                                                    {background: "image_5", win_occurrence:7, prizewinning: true, label: "trip to bahamas"},
                                                    {background: "image_6", win_occurrence:7, prizewinning: true, label: ""},
                                                    {background: "image_7", win_occurrence:7, prizewinning: true, label: ""},
                                                    {background: "image_2", win_occurrence:7, prizewinning: false, label: ""}
                                                    /////////ADD HERE MORE SLOTS IF YOU WANT
                                                ],
                                                total_images_backgrounds_in_folder: 8, 	////SET HERE THE EXACT NUMBER OF BACKGROUND IMAGES IN GAME FOLDER IF YOU WANT TO ADD MORE DIFFERENT IMAGES
                                                num_instant_spin : 3,					///NUMBER OF MAX SPINS
                                                redeem_link: "http://www.codethislab.com/index.php",	///REDIRECT CODE TO REDEEM THE PRIZE


                                                show_credits:true,                      //SET THIS VALUE TO FALSE IF YOU DON'T WANT TO SHOW CREDITS BUTTON
                                                fullscreen:true,                        //SET THIS TO FALSE IF YOU DON'T WANT TO SHOW FULLSCREEN BUTTON
                                                check_orientation:true,                 //SET TO FALSE IF YOU DON'T WANT TO SHOW ORIENTATION ALERT ON MOBILE DEVICES

                                                //////////////////////////////////////////////////////////////////////////////////////////
                                                ad_show_counter: 5     //NUMBER OF SPIN BEFORE AD SHOWN
                                                //
                                                //// THIS FUNCTIONALITY IS ACTIVATED ONLY WITH CTL ARCADE PLUGIN.///////////////////////////
                                                /////////////////// YOU CAN GET IT AT: /////////////////////////////////////////////////////////
                                                // http://codecanyon.net/item/ctl-arcade-wordpress-plugin/13856421?s_phrase=&s_rank=27 ///////////
                                        });


    E) CSS Files and Structure - top

    The game use two CSS files. The first one is a generic reset file. Many browser interpret the default behavior of html elements differently. By using a general reset CSS file, we can work round this. Keep in mind, that these values might be overridden somewhere else in the file.

    The second file contains all of the specific stylings for the canvas and some hack to be fully compatible with all most popular mobile devices


    F) Source Code - top

    This game contains:

    1. jQuery
    2. Our custom scripts
    3. CreateJs plugin
    1. jQuery is a Javascript library that greatly reduces the amount of code that you must write.
    2. The game have the following js files:
      • CMain: the main class called by the index file.
        This file controls the sprite_lib.js file that manages the sprite loading, the loop game and initialize the canvas with the CreateJs library
      • screenfull: this file manages the fullscreen functionality
      • ctl_utils: this file manages the canvas resize and its centering
      • howler.min: this class manages the sounds
      • sprite_lib: this class loads all images declared in the main class
      • settings: general game settings
      • CLang: global string variables for language localization
      • CPreloader: simple text preloader to show resources loading progress
      • CMenu: simple menu with the play button
      • CGfxButton: this class create a standard button
      • CToggle: this class create a standard toggle button
      • CTextButton: this class create a standard text button
      • CGame: this class manages the game logic
      • CInterface: this class controls game GUI that contains text and buttons
      • CHelpPanel: the help panel that is shown before game starting
      • CFormatText: this class manages the texts on the wheel
      • CLeds: this class manages the led animation of the wheel
      • CWheel: this class manages the wheel and its animations
      • CAreYouSurePanel: this class ensure the confirm to exit from game
      • CCircularList: this class adds some help functionality
      • CComplexFrame: this class builds the images of the wheel
      • CCreditsPanel: this class shows the credits
      • CInstantLosePanel: this class shows the lose panel
      • CInstantWinPanel: this class shows the win panel
      • CLoadingPanel: this class shows the loading panel when the wheel's images are loading
      • CReel: this class manages the wheel parts and its animations
      • CTweenController: this class manages the animation ease
    3. CreateJs is a suite of modular libraries and tools which work together to enable rich interactive content on open web technologies via HTML5.

    Resuming, the complete game flow is the following:

    1. The index.html file calls the CMain.js file after ready event is called
    2. The main class calls CPreloader.js to init preloader text and start sprite loading
    3. When all sprites contained in "/sprites" and "/sounds" folder are loaded, the main class removes the preloader and calls the CMenu.js file that shows the main menu
    4. If the user click the Play button in main menu, the CGame.js class is called and game starts
    5. If the user click on the exit button in the down-right corner, the game returns to the menu screen

    G) Game functions - top

    In this section will be explained all the most important functions used in CGame.js file.


    H) Change Graphic - top

    You can easily change all the game graphic, replacing all the file you need in the "/sprites" folder. Just respect file format (.png or .jpg) and size if you don't want to change any code line.

    I) Disable Sounds - top

    If you want to disable all the sounds for mobile devices, you have to change the following value in settings.js file:

    var DISABLE_SOUND_MOBILE = true;

    J) Wheel Customization - top




    K) Wordpress Plugin - top

    CTL Arcade will allow you to add a real arcade on your worpress website, in this way your users will be more involved and will stay connected longer.

    It's possible to add Ads banner at the beginning of each game and at the end of each level. This will give you a new tool to increase your revenues.

    Your own users will promote your website sharing their scores on the main Social Networks, with no extra costs for you.

    You'll get by default the score-sharing on Twitter. To add Facebook just follow the guideline below.

    3 widgets can be added in your pages through a shortcode.

    Minimum Requirements:

    This plugin is designed to work only with games built by Code This Lab.

    You can find it here!

    ctl arcade

    Once again, thank you so much for purchasing this game. Feel free to contact us if you have any questions or issue relating to this game. No guarantees, but we'll do our best to assist.
